100x780 Mesh Inconel Wire Mesh 20 Micron For Filtering No Magnetic

Product Categories

Anping Tianhao Wire Mesh Products Co., Ltd.

Contact Now

Brand Name : TIANHAO

Model Number : 600 601 625

Certification : ISO SGS

Place of Origin : HEBEI, CHINA

MOQ : 1 kg

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : 3-5 days if in stock, 15-25 days if no stock

Packaging Details : water proof paper, bubble bag per roll, then put in wooden pallet or wooden case, or as customer's requirement

Name : 20 micron 100x780 mesh inconel 600 601 alloy wire mesh screen for filtering

Material : 600 (N06600)、Inconel 601 (N06601)、Inconel 625 (N06625)

Mesh : 1 to 200 Mesh

Width : 0.6 to 2.5m

Length : 30m or as per customer's request

Feature : No magnetic

Sample : Available

Customized : Available

Contact Now

20 micron 100x780 mesh inconel 600 601 alloy wire mesh screen for filtering

Inconel Woven Wire Mesh

1. Material:Inconel 600 (N06600),Inconel 601 (N06601),Inconel 625 (N06625),Inconel 718 (N07718),Inconel X-750 (N07750)

2. Mesh Count: 2-200

3. Weaving: Plain weave,Twill weave

4. Chemical Composistion

Grade	C	Cr	Cu	Fe	Mn	Ni	S	Si
Inconel 600	0.15	14 - 17	0.5	6 - 10	1.0	72.0	0.015	0.5

Grade	C	Cr	Cu	Fe	Mn	Ni	S	Si	Al
Inconel 601	0.1	21 - 25	1.0	Rem.	1.0	58 - 63	0.015	0.5	1.0 - 1.7

Grade	C	Cr	Fe	Mn	Ni	S	Si	Al	Cb	Mo	P	Ti
Inconel 625	0.1	20 - 23	5.0	0.5	Rem.	0.15	0.5	0.4	3.15 - 4.15	8 - 10	0.015	0.4

5. Features of Inconel Woven Wire Mesh

Non-magnetic

Good oxidation resistance and high temperature resistance

Petrochemical, aerospace industry, hydropower, nuclear power, oil refining and shipbuilding, chemical, machinery manufacturing industries.

Good resistance to corrosion and cracking under normal or high temperature conditions

Good mechanical properties.

6. The main areas of application

Item	Inconel Wire Mesh
Material	Inconel 600, Inconel 601, Inconel 625
Main Content	Ni, Cr and Fe
Weaving Type	Plain and Twill Weave
Specification	Mesh 2 to 200
Feature	No Magnetic, Good mechanical.
Application	Aerospace industry, Nuclear power, Oil refining or Chemical

100x780 Mesh Inconel Wire Mesh 20 Micron For Filtering No Magnetic
